Solar Panel Controller 10A20A30A 12V24V Auto Battery Charge Regulator PWM Controller LCD Dual USB for PV Home
Solar Panel Controller 10A20A30A 12V24V Auto Battery Charge Regulator PWM Controller LCD Dual USB for PV Home
Solar Panel Controller 10A20A30A 12V24V Auto Battery Charge Regulator PWM Controller LCD Dual USB for PV Home
This controller is a intelligent, multi-purpose solar charge and discharge controller. Fixed LCD display with a very friendly interface is used in this product; various control parameters can be flexibly set, fully meet your various application requirements.
This is NEW Solar Controller ,It can fully meet your home Photovoltaic system(including home lighting system)requirements.It can recongize 12V and 24V Lead acid ,Gel battery automatically.
There are optional 10A 20A 30A model
10A:
if your battery is 12V ,the max solar panel input is 25V 120W
if your battery is 24V ,the max solar panel input is 50V 240W
20A:
if your battery is 12V, the max solar panel input is 25V 240W
if your battery is 24V, the max solar panel input is 50V 480W
30A:
if your battery is 12V ,the max solar panel input is 25V 360W
if your battery is 24V ,the max solar panel input is 50V 720W
Features:
1.Build-in industrial micro controller.
2.Big LCD display,all adjustable parameter.
3.Fully 4-stage PWM charge management.
4.Build-in short-circuit protection,open-circuit protection,reverse protection,over-load protection.
5.Dual mosfet Reverse current protection ,low heat production.
6.The regulator is only suitable for lead acid batteries:OPEN,AGM,GEL
it is not suited for nickel metal hydride,lithium ions or other batteries.
7.The charge regulator is only suitable for regulating solar modules.
Never connect another charging source to the charge regulator.
Model |
PWM 10A |
PWM 20A |
PWM30A |
|
Battery Voltage |
12V 24V Auto |
|||
Charging Current |
10A |
20A |
30A |
|
Discharging Current |
10A |
10A |
10A |
|
Max.Solar Input |
50V(for 24V battery) 25V(for 12V battery) |
|||
Equalization |
14.4V(Sealed) 14.2V(Gel) 14.6V(Flod) |
|||
Float charge |
13.7V(defaul,adjustable) |
|||
Discharge stop |
10.7V(defaul,adjustable) |
|||
Discharge reconnect |
12.6V(defaul,adjustable) |
|||
Charge reconnect |
13V |
|||
Voltage of open light |
Solar Panel 8V(Light lights delay) |
|||
Voltage of close light |
Solar Panel 8V(Light off delay) |
|||
USB Output |
5V/3A |
|||
Self-consume |
<10mA |
|||
Operating temperature |
-35 °C to 60°C |
|||
Size |
133.5*70*35mm |
